Automatic CNC Spring Machine with 0.3-2.5MM Wire Size 10 Axes Servo Motors and 1 Year Warranty

Détails sur le produit:

Lieu d'origine:	Guangdong, Chine
Nom de marque:	HYD

Conditions de paiement et expédition:

Quantité de commande min:	1

Contact

Description de produit détaillée

Poids:	900 kg	Tension:	380 V
Pouvoir:	9.35 kW	Taille:	0.3-2.5 millimètre
Servomoteur:	10 haches	Max Wire Speed:	110 m/min
Stockage de programme:	1000	Rail de plomb:	80 mm
Rouleau d'alimentation en fil:	2 paires	Erreur maximum:	± 0,03 (longueur)
Marque motrice:	SANYO	Longueur d'ange la plus courte:	4 fois diamètre de fil
Alimentation électrique:	380 V ± 10 % V 50 Hz	Décolleter:	200 kg
Taille de la machine:	L1400L950H1700mm
Mettre en évidence:	1 Year Warranty CNC Spring Machine , OEM Service Automatic Spring Machine , 0.3-2.5MM Wire Size Computer Spring Machine

Automatic Spring Machine Spring Forming Machine HYD-25T-10A 0.3-2.5MM

Product Description

The HYD-25T-10A/12A is a multi-function computer spring machine designed for precision spring manufacturing with wire sizes ranging from 0.3-2.5mm.

Technical Specifications

Model	HYD-25T-10A	HYD-25T-12A
Wire Size	0.3-2.5mm	0.3-2.5mm
Servo Motors	10 axes	12 axes
Lead Rail	tineraries 80mm	tineraries 80mm
Wire Feed Roller	2 Pairs	4 Pairs
Maximum error	±0.03(Length)	±0.03(Length)
MaxWire Feed Speed	110m/min	110m/min
Motor Brand	Sanyo	Sanyo
Shortest Angel Length	4 Times Wire Diameter	4 Times Wire Diameter
Power Supply	380V±10%V50Hz	380V±10%V50Hz
Decoiler	200KG	500KG
Machine Dimension	900KG	1300KG
Machine Size	L1400W950H1700MM	L1700W1150H1700MM

Product Gallery

Frequently Asked Questions

Q1: Can you send me the catalogue?

A1: Sure. We have different kinds of machines catalog here. Or you can also tell me what products you need.

Q2: Do you accept OEM?

A2: We can produce any of your requested designs.

Q3: Can it be configured with something else?

A3: Yes, We can customize the machine according to your product requirements.

Q4: Are you a factory?

A4: Sure. We are factory direct sales; welcome to visit our factory.

Q5: What information will be helpful in getting an accurate quotation from us?

A5: The customer should provide the related drawings, pictures, industrial voltage, planned output, technical requirements, etc.

Q6: What is the power supply of the machine?

A6: The standard power supply in China is 380V, 3P, 50Hz. We also can customized as per requirement.

Q7: What is the payment term?

A7: The payment term is 30% deposit as PO confirmation, and 70% should be finished before the shipment. We also accept other payment terms.

Q8: What is the delivery time?

A8: Normally the manufacturing time of the machine is 30 days after receiving deposit. But it depends on machine model. Some machine production can be finished within 15 days.

Q9: What is the guarantee period of the machine?

A9: The guarantee period is one year from the date of B/L.

Q10: What is the MOQ?

A10: One set. We will make the machine suitable for you according to your needs.

Q11: How can I contact you to place an order?

A11: You can contact us by email or WhatsApp, or by whatever method you prefer.

Q12: What types of products are there?

A12: We have camless spring machines, cam spring machines, compression spring machines, wire bending machines, rotary head machines, etc.

Q13: Do you have CE certification?

A13: Yes, we have CE certificate. Our machines are of good quality and high precision.

Q14: What motor do you use?

A14: We use Japanese Sanyo servo motors. Can also be customized according to your needs.

Q15: What terms do you accept?

A15: We accept FOB, CIF, EXW, etc.

Q16: Do you provide training?

A16: Yes, our engineers can provide machine training services, you can come to our factory to learn, or we can also arrange online guidance.

Q17: Do you offer the service of purchasing accessories separately?

A17: Yes, you can ask us about accessories and provide some corresponding sizes and information.

Q18: What is your packaging like?

A18: We use standard seaworthy wooden boxes to pack our goods.

Q19: How to operate the machine?

A19: Our machines are controlled by computer systems. We will provide user manuals for operating the computer systems. If you have any questions, we will also arrange for engineers to answer them.

Q20: Can your computer system switch the language?

A20: Yes, usually we will set the system to English mode before shipping.
